FZB series Fluoroplastic Lined Self-Priming Pump

Thefzb self-priming pump (FZB Series) is a high-performance fluoroplastic lined pump specifically engineered for handling strong acids, alkalis, organic solvents, and severely corrosive fluids. Constructed with a heavy-duty cast iron outer casing and premium F46/PTFE fluoropolymer lining, this premium ptfe lined pump delivers superior corrosion resistance, high pressure durability, and hassle-free rapid self-priming without a foot valve.

Key Features

• Extreme Corrosion Resistance: Premium F46 fluoroplastic lining handles any concentration of hydrochloric acid, sulfuric acid, nitric acid, hydrofluoric acid, strong alkalis, and organic solvents where stainless steel fails.

• Steel-Lined Robust Construction: The ductile iron/cast iron outer shell provides exceptional structural strength and shock resistance compared to pure plastic pumps, ensuring long-term pressure resistance.

• Self-Priming Without Foot Valve: Requires water priming only prior to the initial startup. Subsequent operations feature automatic self-priming capability for convenient unloading from lower storage tanks or tanker trucks.

• External Mechanical Seal: Easy maintenance and replacement without disconnecting pipeline connections.

• Safe & Environmentally Friendly: Sealed construction prevents chemical leaking or dripping, protecting plant operators and working environments.

• Submersible Replacement: Ideal alternative to submerged vertical pumps, eliminating underground maintenance and corrosion issues.

Applications

• Chemical & Pharmaceutical Manufacturing: Acids, alkalis, agrochemicals, dyes, fine chemicals, and process fluid transfer.

• Electroplating & PCB Circuit Board Industry: Acid washing circulation, etching solution transfer, and hazardous gas scrubbing systems.

• Non-Ferrous Metallurgy & Mining: Rare earth extraction, electrolyte circulation, and acid leaching process.

• Chemical Tanker Unloading: Tanker truck unloading, underground acid tank suction, and corrosive wastewater lifting.
