Designed specifically for outdoor operations, emergency drainage, agricultural irrigation, and remote project sites without stable power supply, these diesel engine pumps perform exceptionally well in municipal engineering, construction dewatering, and flood control. Utilizing high-grade heavy-duty diesel engines coupled with robust centrifugal pump ends, these units offer reliable self-priming capability and high operational efficiency. Custom skid-mounted, trailer-mounted, and sound-attenuated structural options are fully supported to match specialized job-site requirements.

Key Technical Range:

Size Range: DN25 – DN300
Flow Range: 3.25 - 6500 m³/h
Head Range: 2 - 140 m
Engine Power: 0.22 - 1600 /kW (covering Gasoline, Single-Cylinder Diesel, and multi-cylinder engines)
Suction Lift: 5 - 9.5 m (Depending on specific self-priming/sewage models)
Speed: 585 - 2950 r/min
Efficiency η: 37 - 89%
NPSHr: 2.0 - 7.1 m
Customization: Trailer-Mounted, Weatherproof Canopy, Non-Standard Skid Customization Available
