Horizontal End Suction Centrifugal Pump (ISW/IHW Series)

Model NO. Horizontal End Suction Centrifugal Pump (ISW/IHW Series)

Pump material: Cast Iron, Stainless Steel, Duplex Steel

Flow Range: 2.8 - 1450 m³/h

Head Range: 8.4 - 156 m

Motor Power: 0.55 - 250 kW

Speed: 980 -2960 r/min

Voltage: 220V / 380V / 415V / 440V / 460V

What is Horizontal End Suction Centrifugal Pump (ISW/IHW Series)？

TheISW, ISWR, ISWH, ISWY, ISWHY, ISWD, ISWRD, ISWHD, ISWYD, and ISWHYD series horizontal centrifugal pumps are designed based on the performance parameters of IS and IR centrifugal pumps, with reference to the ISO2858 standard, and optimized using excellent Chinese hydraulic models. They are an ideal new generation of high-efficiency and energy-saving horizontal pump products.

Features

Compact Structure: This series of pumps has a horizontal structure with integrated motor and pump design, appealing appearance, and small footprint. Compared with ordinary horizontal pumps, the footprint is reduced by 30%. If equipped with an IP54 outdoor motor, no pump house is required and it can be placed outdoors.
Smooth Operation, Low Noise & High Concentricity: The direct connection between the motor and pump simplifies the intermediate structure and enhances operational stability. The impeller has excellent dynamic and static balance, resulting in low vibration and noise during operation, extending bearing service life and improving the operating environment.
High-Quality Mechanical Seal: The shaft seal uses a high-quality mechanical seal, with dynamic and static rings made of carbide, offering wear resistance, low leakage, and long service life.
Advanced Hydraulic Model: Adopts advanced hydraulic models, featuring high efficiency and good performance.
Unique Structure: The bottom side of the pump body is equipped with a water drain hole, and the inlet and outlet flanges are equipped with pressure sampling holes, ensuring proper use and maintenance of the pump.
Convenient Piping Layout: The inlet of this series of horizontal pumps is in the horizontal direction, while the outlet is in the vertical upward direction, facilitating pipeline arrangement.

Operating Conditions

System Pressure Limits: The maximum working pressure of the pump system is 1.6 MPa, i.e., pump inlet pressure + pump head ≤1.6 MPa (When pump system working pressure is higher than 1.6 MPa, it should be specified separately when ordering so that cast steel can be used for flow passage components and connecting parts during manufacturing).
Conveyed Media: Conveyed media is clean water or other liquids with physical and chemical properties similar to clean water (When conveyed media contains fine particles, it should be specified separately when ordering so that a wear-resistant mechanical seal can be installed).
Ambient Conditions: Ambient temperature does not exceed 40°C, altitude does not exceed 1000 m, and relative humidity does not exceed 95%.

Applications

ISW Horizontal Centrifugal Pump: Used for conveying clean water and other liquids with physical and chemical properties similar to clean water. Suitable for industrial and urban water supply and drainage, high-rise building pressurized water supply, marine applications, garden sprinkler irrigation, fire boosting, long-distance delivery, HVAC refrigeration circulation, bathroom cold/hot water circulation, and equipment matching. Operating media temperature does not exceed 85°C.
ISWR Horizontal Hot Water Circulation Pump: Suitable for energy, metallurgy, wood processing, chemical industry, textile, paper making, restaurants, bathrooms, hotels, boiler hot water boosting circulation, and urban residential heating circulation systems. Operating temperature does not exceed 120°C.
ISWH Horizontal Chemical Centrifugal Pump: Suitable for petroleum, chemical, metallurgy, power, paper making, food, pharmaceutical, and synthetic fiber industries to convey corrosive liquids. Operating temperature: -20°C to 105°C.
ISWY Horizontal Explosion-Proof Oil Pump: Suitable for petroleum, light textile, chemical, machinery, and other industries to convey flammable and explosive liquids. Conveyed media temperature does not exceed 120°C.
ISWHY Horizontal Stainless Steel Explosion-Proof Chemical Centrifugal Pump: Suitable for conveying flammable and explosive chemical liquids.
ISWD, ISWRD, ISWHD, ISWYD, ISWHYD Horizontal Low-Speed Centrifugal Pumps: Suitable for occasions with higher requirements for ambient noise, especially for chilled water/cooling water circulation and terminal boosting in air conditioning systems.

ISW Series Horizontal End Suction Centrifugal Pump Model Designation Chart | JPZX

Model	Flow Rate (m³/h)	Flow Rate (L/s)	Head (m)	Efficiency (%)	Motor Power (kW)	Speed (r/min)	NPSHr (m)	Weight (kg)
25-110	2.8	0.78	16	34	0.55	2900	2.3	33
25-110	4	1.11	15	42	0.55	2900	2.3	33
25-110	5.2	1.44	13.5	41	0.55	2900	2.3	33
25-125	2.8	0.78	20.6	28	0.75	2900	2.3	37
25-125	4	1.11	20	36	0.75	2900	2.3	37
25-125	5.2	1.44	18	35	0.75	2900	2.3	37
25-125A	2.5	0.69	17	27	0.75	2900	2.3	37
25-125A	3.6	1.0	16	35	0.75	2900	2.3	37
25-125A	4.6	1.28	14.4	34	0.75	2900	2.3	37
25-160	2.8	0.78	33	24	1.5	2900	2.3	46
25-160	4	1.11	32	32	1.5	2900	2.3	46
25-160	5.2	1.44	30	33	1.5	2900	2.3	46
25-160A	2.6	0.72	28.5	22	1.1	2900	2.3	42
25-160A	3.7	1.03	28	31	1.1	2900	2.3	42
25-160A	4.9	1.36	26	29	1.1	2900	2.3	42
32-100	3.5	0.97	13.5	40	0.55	2900	2.3	37
32-100	4.5	1.25	12.5	47	0.55	2900	2.3	37
32-100	5.3	1.47	11.0	43	0.55	2900	2.3	37
32-100(I)	4.4	1.22	13.2	48	0.75	2900	2.0	40
32-100(I)	6.3	1.75	12.5	54	0.75	2900	2.0	40
32-100(I)	8.3	2.32	11.3	53	0.75	2900	2.0	40
32-125	3.5	0.97	22	40	0.75	2900	2.3	40
32-125	5	1.39	20	44	0.75	2900	2.3	40
32-125	6.5	1.80	18	42	0.75	2900	2.3	40
32-125A	3.1	0.86	17.6	39	0.75	2900	2.3	39
32-125A	4.5	1.25	16	43	0.75	2900	2.3	39
32-125A	5.8	1.61	14.4	41	0.75	2900	2.3	39
32-160	3.5	0.97	33	30	1.5	2900	2.3	51
32-160	4.5	1.25	32	35	1.5	2900	2.3	51
32-160	6	1.67	30	33	1.5	2900	2.3	51
32-160A	3.5	0.97	26.5	29	1.1	2900	2.3	45
32-160A	4.5	1.25	25	34	1.1	2900	2.3	45
32-160A	6	1.67	23	32	1.1	2900	2.3	45
32-160(I)	4.4	1.22	33.2	24	2.2	2900	2.3	55
32-160(I)	6.3	1.75	32	32	2.2	2900	2.3	55
32-160(I)	8.3	2.32	30.2	33	2.2	2900	2.3	55
32-200	3.5	0.97	51	27	3	2900	2.3	71
32-200	4.5	1.25	50	32	3	2900	2.3	71
32-200	5.5	1.53	48	30	3	2900	2.3	71
32-200(I)	4.4	1.22	50.5	26	4	2900	2.3	76
32-200(I)	6.3	1.75	50	33	4	2900	2.3	76
32-200(I)	8.3	2.32	48	35	4	2900	2.3	76
32-200A	3.9	1.08	41	26	3	2900	2.3	61
32-200A	4	1.11	40	31	3	2900	2.3	61
32-200A	4.2	1.17	38	29	3	2900	2.3	61
40-100	4.4	1.22	13.2	48	0.55	2900	2.3	34
40-100	6.3	1.75	12.5	54	0.55	2900	2.3	34
40-100	8.3	2.31	11.3	53	0.55	2900	2.3	34
40-100A	3.9	1.08	10.6	52	0.37	2900	2.3	25
40-100A	5.6	1.56	10	52	0.37	2900	2.3	25
40-100A	7.4	2.06	9	52	0.37	2900	2.3	25
40-125	4.4	1.22	21	41	1.1	2900	2.3	35
40-125	6.3	1.75	20	46	1.1	2900	2.3	35
40-125	8.3	2.31	18	43	1.1	2900	2.3	35
40-125A	3.9	1.08	17.6	40	0.75	2900	2.3	31
40-125A	5.6	1.56	16	45	0.75	2900	2.3	31
40-125A	7.4	2.06	14.4	41	0.75	2900	2.3	31
40-160	4.4	1.22	33	35	2.2	2900	2.3	50
40-160	6.3	1.75	32	40	2.2	2900	2.3	50
40-160	8.3	2.31	30	40	2.2	2900	2.3	50
40-160A	4.1	1.14	29	34	1.5	2900	2.3	44
40-160A	5.9	1.64	28	39	1.5	2900	2.3	44
40-160A	7.8	2.17	26.3	39	1.5	2900	2.3	44
40-160B	3.8	1.06	25.5	34	1.1	2900	2.3	37
40-160B	5.5	1.53	24	38	1.1	2900	2.3	37
40-160B	7.2	2.0	22.5	37	1.1	2900	2.3	37
40-200	4.4	1.22	51	26	4	2900	2.3	76
40-200	6.3	1.75	50	33	4	2900	2.3	76
40-200	8.3	2.31	48	32	4	2900	2.3	76
40-200A	4.1	1.14	45	26	3	2900	2.3	64
40-200A	5.9	1.64	44	31	3	2900	2.3	64
40-200A	7.8	2.17	42	30	3	2900	2.3	64
40-200B	3.7	1.03	38	25	2.2	2900	2.3	54
40-200B	5.3	1.47	36	29	2.2	2900	2.3	54
40-200B	7.0	1.94	34.5	28	2.2	2900	2.3	54
40-250	4.4	1.22	82	24	7.5	2900	2.3	108
40-250	6.3	1.75	80	28	7.5	2900	2.3	108
40-250	8.3	2.31	74	28	7.5	2900	2.3	108
40-250A	4.1	1.17	72	24	7.5	2900	2.3	100
40-250A	5.9	1.64	70	28	7.5	2900	2.3	100
40-250A	7.8	2.17	65	27	7.5	2900	2.3	100
40-250B	3.7	1.06	61.5	23	4	2900	2.3	80
40-250B	5.5	1.53	60	27	4	2900	2.3	80
40-250B	7.0	1.94	56	26	4	2900	2.3	80
40-100(I)	8.8	2.44	13.2	55	1.1	2900	2.3	36
40-100(I)	12.5	3.47	12.5	62	1.1	2900	2.3	36
40-100(I)	16.3	4.53	11.3	60	1.1	2900	2.3	36
40-100(I)A	8	2.22	10.6	54	0.75	2900	2.3	34
40-100(I)A	11	3.05	10	60	0.75	2900	2.3	34
40-100(I)A	14.5	4.03	9	58	0.75	2900	2.3	34
40-125(I)	8.8	2.44	21.2	49	1.5	2900	2.3	40
40-125(I)	12.5	3.47	20	58	1.5	2900	2.3	40
40-125(I)	16.3	4.53	17.8	57	1.5	2900	2.3	40
40-125(I)A	8	2.22	17	48	1.1	2900	2.3	35
40-125(I)A	11	3.05	16	57	1.1	2900	2.3	35
40-125(I)A	14.5	4.03	14	56	1.1	2900	2.3	35
40-160(I)	8.8	2.44	33	45	3	2900	2.3	58
40-160(I)	12.5	3.47	32	52	3	2900	2.3	58
40-160(I)	16.3	4.53	30	51	3	2900	2.3	58
40-160(I)A	8.2	2.28	29	44	2.2	2900	2.3	49
40-160(I)A	11.7	3.25	28	51	2.2	2900	2.3	49
40-160(I)A	15.2	4.22	26	50	2.2	2900	2.3	49
40-160(I)B	7.3	2.38	23	50	1.5	2900	2.3	44
40-160(I)B	10.4	2.89	22	50	1.5	2900	2.3	44
40-160(I)B	13.5	3.75	20.5	50	1.5	2900	2.3	44
40-200(I)	8.8	2.44	51.2	38	5.5	2900	2.3	87
40-200(I)	12.5	3.47	50	46	5.5	2900	2.3	87
40-200(I)	16.3	4.53	48	46	5.5	2900	2.3	87
40-200(I)A	8.3	2.31	45	37	4.0	2900	2.3	76
40-200(I)A	11.7	3.25	44	45	4.0	2900	2.3	76
40-200(I)A	15.3	4.25	42	45	4.0	2900	2.3	76
40-200(I)B	7.5	2.00	37	36	3.0	2900	2.3	65
40-200(I)B	10.6	2.92	36	44	3.0	2900	2.3	65
40-200(I)B	13.8	3.83	34	44	3.0	2900	2.3	65
40-250(I)	8.8	2.44	81.2	31	11	2900	2.3	148
40-250(I)	12.5	3.47	80	40	11	2900	2.3	148
40-250(I)	16.3	4.53	77.5	38	11	2900	2.3	148
40-250(I)A	8.2	2.28	71	30	7.5	2900	2.3	98
40-250(I)A	11.7	3.22	70	38	7.5	2900	2.3	98
40-250(I)A	15.2	4.22	68	36	7.5	2900	2.3	98
40-250(I)B	7.6	2.11	61.4	29	5.5	2900	2.3	97
40-250(I)B	10.8	3.0	60	37	5.5	2900	2.3	97
40-250(I)B	14	3.89	58	35	5.5	2900	2.3	97
50-100	8.8	2.44	13.6	55	1.1	2900	2.3	38
50-100	12.5	3.47	12.5	62	1.1	2900	2.3	38
50-100	16.3	4.53	11.3	60	1.1	2900	2.3	38
50-100A	8	2.22	11	54	0.75	2900	2.3	37
50-100A	11	3.05	10	60	0.75	2900	2.3	37
50-100A	14.5	4.03	9	58	0.75	2900	2.3	37
50-125	8.8	2.44	21.5	49	1.5	2900	2.3	44
50-125	12.5	3.47	20	58	1.5	2900	2.3	44
50-125	16.3	4.53	17.8	57	1.5	2900	2.3	44
50-125A	8	2.22	17	48	1.1	2900	2.3	39
50-125A	11	3.05	16	57	1.1	2900	2.3	39
50-125A	14.5	4.03	14	56	1.1	2900	2.3	39
50-160	8.8	2.44	33	45	3	2900	2.3	60
50-160	12.5	3.47	32	52	3	2900	2.3	60
50-160	16.3	4.53	30	51	3	2900	2.3	60
50-160A	8.2	2.28	29	44	2.2	2900	2.3	52
50-160A	11.7	3.25	28	51	2.2	2900	2.3	52
50-160A	15.2	4.22	26	50	2.2	2900	2.3	52
50-160B	7.3	2.38	23	43	1.5	2900	2.3	48
50-160B	10.4	2.89	22	50	1.5	2900	2.3	48
50-160B	13.5	3.75	20.5	49	1.5	2900	2.3	48
50-200	8.8	2.44	52	38	5.5	2900	2.3	104
50-200	12.5	3.47	50	46	5.5	2900	2.3	104
50-200	16.3	4.53	48	46	5.5	2900	2.3	104
50-200A	8.3	2.31	45.8	37	4	2900	2.3	82
50-200A	11.7	3.25	44	45	4	2900	2.3	82
50-200A	15.3	4.25	48	45	4	2900	2.3	82
50-200B	7.5	2.08	37	38	3	2900	2.3	69
50-200B	10.6	2.94	36	44	3	2900	2.3	69
50-200B	13.8	3.83	34	40	3	2900	2.3	69
50-250	8.8	2.44	82	29	11	2900	2.3	163
50-250	12.5	3.47	80	40	11	2900	2.3	163
50-250	16.3	4.53	77.5	38	11	2900	2.3	163
50-250A	8.2	2.28	71.5	28	7.5	2900	2.3	116
50-250A	11.6	3.22	70	38	7.5	2900	2.3	116
50-250A	15.2	4.22	68	36	7.5	2900	2.3	116
50-250B	7.6	2.11	61.4	27	7.5	2900	2.3	114
50-250B	10.8	3	60	37	7.5	2900	2.3	114
50-250B	14	3.89	58	35	7.5	2900	2.3	114
50-100(I)	17.5	4.86	13.7	67	1.5	2900	2.5	43
50-100(I)	25	6.94	12.5	69	1.5	2900	2.5	43
50-100(I)	32.5	9.03	10.5	69	1.5	2900	2.5	43
50-100(I)A	15.6	4.3	11	65	1.1	2900	2.5	38
50-100(I)A	22.3	6.19	10	67	1.1	2900	2.5	38
50-100(I)A	29	8.1	8.4	68	1.1	2900	2.5	38
50-125(I)	17.5	4.86	21.5	60	3	2900	2.5	58
50-125(I)	25	6.94	20	68	3	2900	2.5	58
50-125(I)	32.5	9.03	18	67	3	2900	2.5	58
50-125(I)A	15.6	4.33	17	58	2.2	2900	2.5	50
50-125(I)A	22.3	6.19	16	66	2.2	2900	2.5	50
50-125(I)A	29	8.1	13.6	65	2.2	2900	2.5	50
50-160(I)	17.5	4.68	34.4	54	4	2900	2.5	74
50-160(I)	25	6.94	32	63	4	2900	2.5	74
50-160(I)	32.5	9.03	27.5	60	4	2900	2.5	74
50-160(I)A	16.4	4.56	30	54	4	2900	2.5	72
50-160(I)A	23.4	6.5	28	62	4	2900	2.5	72
50-160(I)A	30.4	8.44	24	59	4	2900	2.5	72
50-160(I)B	15	4.17	26	51	3	2900	2.5	61
50-160(I)B	21.6	6	24	58	3	2900	2.5	61
50-160(I)B	28	7.78	20.6	56	3	2900	2.5	61
50-200(I)	17.5	4.86	52.7	53	7.5	2900	2.5	113
50-200(I)	25	6.94	50	60	7.5	2900	2.5	113
50-200(I)	32.5	9.03	45.5	58	7.5	2900	2.5	113
50-200(I)A	16.4	4.56	46.4	49	7.5	2900	2.5	111
50-200(I)A	23.5	6.53	44	58	7.5	2900	2.5	111
50-200(I)A	30.5	8.47	40	54	7.5	2900	2.5	111
50-200(I)B	15.2	4.2	40	47	5.5	2900	2.5	104
50-200(I)B	21.8	6.06	38	55	5.5	2900	2.5	104
50-200(I)B	28.3	7.86	34.5	51	5.5	2900	2.5	104
50-250(I)	17.5	4.86	82	49	15	2900	2.5	180
50-250(I)	25	6.94	80	52	15	2900	2.5	180
50-250(I)	32.5	9.03	76.2	50	15	2900	2.5	180
50-250(I)A	16.4	4.56	71.5	45	11	2900	2.5	170
50-250(I)A	23.4	6.53	70	51	11	2900	2.5	170
50-250(I)A	30.5	8.47	67	47	11	2900	2.5	170
50-250(I)B	15	4.17	61	38	11	2900	2.5	170
50-250(I)B	21.6	6	60	54	11	2900	2.5	170
50-250(I)B	28	7.78	57.4	49	11	2900	2.5	170
50-315(I)	17.5	4.86	128	38	30	2900	2.5	313
50-315(I)	25	6.94	125	44	30	2900	2.5	313
50-315(I)	32.5	9.03	122	40	30	2900	2.5	313
50-315(I) A	16.6	4.16	115	37	22	2900	2.5	247
50-315(I) A	23.7	6.58	113	43	22	2900	2.5	247
50-315(I) A	31	8.6	112	40	22	2900	2.5	247
50-315(I) B	15.7	4.36	103	33	18.5	2900	2.5	217
50-315(I) B	22.5	6.25	101	39	18.5	2900	2.5	217
50-315(I) B	29.2	8.1	98	37	18.5	2900	2.5	217
65-100	17.5	4.86	13.7	67	1.5	2900	2.5	48
65-100	25	6.94	12.5	69	1.5	2900	2.5	48
65-100	32.5	9.03	10.5	68	1.5	2900	2.5	48
65-100A	15.6	4.3	11	65	1.1	2900	2.5	42
65-100A	22.3	6.19	10	68	1.1	2900	2.5	42
65-100A	29	8.1	8.4	67	1.1	2900	2.5	42
65-125	17.5	4.86	21.5	61	3	2900	2.5	60
65-125	25	6.94	20	68	3	2900	2.5	60
65-125	32.5	9.03	18	66	3	2900	2.5	60
65-125A	15.6	4.33	17	58	2.2	2900	2.5	49
65-125A	22.3	6.19	16	66	2.2	2900	2.5	49
65-125A	29	8.1	14.4	65	2.2	2900	2.5	49
65-160	17.5	4.86	34.4	54	4	2900	2.5	77
65-160	25	6.94	32	63	4	2900	2.5	77
65-160	32.5	9.03	27.5	60	4	2900	2.5	77
65-160A	16.4	4.56	30	54	4	2900	2.5	76
65-160A	23.4	6.5	28	62	4	2900	2.5	76
65-160A	30.4	8.44	24	59	4	2900	2.5	76
65-160B	15	4.17	26	51	3	2900	2.5	63
65-160B	21.6	6	24	58	3	2900	2.5	63
65-160B	28	7.78	20.6	56	3	2900	2.5	63
65-200	17.5	4.86	52.7	49	7.5	2900	2.5	110
65-200	25	6.94	50	60	7.5	2900	2.5	110
65-200	32.5	9.03	45.5	58	7.5	2900	2.5	110
65-200A	16.4	4.56	46.4	48	5.5	2900	2.5	109
65-200A	23.5	6.53	44	58	5.5	2900	2.5	109
65-200A	30.5	8.47	40	57	5.5	2900	2.5	109
65-200B	15.2	4.22	40	47	5.5	2900	2.5	101
65-200B	21.8	6.06	38	55	5.5	2900	2.5	101
65-200B	28.3	7.86	34.5	51	5.5	2900	2.5	101
65-250	17.5	4.86	82	39	15	2900	2.5	185
65-250	25	6.94	80	52	15	2900	2.5	185
65-250	32.5	9.03	76.5	50	15	2900	2.5	185
65-250A	16.4	4.56	71.5	47	11	2900	2.5	173
65-250A	23.4	6.5	70	51	11	2900	2.5	173
65-250A	30.5	8.47	67	48	11	2900	2.5	173
65-250B	15	4.17	61	38	11	2900	2.5	173
65-250B	21.6	6	60	49	11	2900	2.5	173
65-250B	28	7.78	57.4	54	11	2900	2.5	173
65-315	17.5	4.86	127	32	30	2900	2.5	325
65-315	25	6.94	125	40	30	2900	2.5	325
65-315	32.5	9.03	122	44	30	2900	2.5	325
65-315A	16.6	4.61	115	32	22	2900	2.5	258
65-315A	23.7	6.58	113	40	22	2900	2.5	258
65-315A	31	8.6	110	44	22	2900	2.5	258
65-315B	15.7	4.36	103	39	18.5	2900	2.5	229
65-315B	22.5	6.25	101	39	18.5	2900	2.5	229
65-315B	29.2	8.1	98	39	18.5	2900	2.5	229
65-100(I)	35	9.72	13.8	67	3	2900	3	65
65-100(I)	50	13.9	12.5	73	3	2900	3	65
65-100(I)	65	18.1	10	70	3	2900	3	65
65-100(I)A	31.3	8.7	11	66	2.2	2900	3	54
65-100(I)A	44.7	12.4	10	72	2.2	2900	3	54
65-100(I)A	58	16.1	8	69	2.2	2900	3	54
65-125(I)	35	9.72	22	67	5.5	2900	3	100
65-125(I)	50	13.9	20	72.5	5.5	2900	3	100
65-125(I)	65	18.1	17	70	5.5	2900	3	100
65-125(I)A	31.3	8.7	17.5	66	4	2900	3	79
65-125(I)A	45	12.5	16	71	4	2900	3	79
65-125(I)A	58	16.1	13.6	69	4	2900	3	79
65-160(I)	35	9.27	35	63	7.5	2900	3	105
65-160(I)	50	13.9	32	73	7.5	2900	3	105
65-160(I)	65	18.1	28	70	7.5	2900	3	105
65-160(I)A	32.7	9.1	30.6	62	7.5	2900	3	104
65-160(I)A	46.7	13	28	70	7.5	2900	3	104
65-160(I)A	61	16.9	24	69	7.5	2900	3	104
65-160(I)B	30.3	8.4	26	61	5.5	2900	3	98
65-160(I)B	43.3	12	24	69	5.5	2900	3	98
65-160(I)B	56.3	15.6	21	68	5.5	2900	3	98
65-200(I)	35	9.72	53.5	55	15	2900	3	179
65-200(I)	50	13.9	50	69	15	2900	3	179
65-200(I)	65	18.1	46	67	15	2900	3	179
65-200(I)A	32.8	9.1	47	54	11	2900	3	168
65-200(I)A	47	13.1	44	67	11	2900	3	168
65-200(I)A	61	16.9	40	66	11	2900	3	168
65-200(I)B	30.5	8.5	40.6	53	7.5	2900	3	115
65-200(I)B	43.5	12.1	38	65	7.5	2900	3	115
65-200(I)B	56.3	15.7	33.4	64	7.5	2900	3	115
65-250(I)	35	9.72	83	52	22	2900	3	238
65-250(I)	50	13.9	80	62	22	2900	3	238
65-250(I)	65	18.1	72	59	22	2900	3	238
65-250(I)A	32.5	9	73	58	18.5	2900	3	207
65-250(I)A	46.7	13	70	60	18.5	2900	3	207
65-250(I)A	61	16.9	63	58	18.5	2900	3	207
65-250(I)B	30	8.3	62	56	15	2900	3	182
65-250(I)B	43.3	12	60	58	15	2900	3	182
65-250(I)B	56	15.6	54	57	15	2900	3	182
65-315(I)	35	9.72	128	44	37	2900	3	353
65-315(I)	50	13.9	125	54	37	2900	3	353
65-315(I)	65	18.1	121	57	37	2900	3	353
65-315(I)A	32.5	9	112.6	43	30	2900	3	336
65-315(I)A	46.5	12.9	110	54	30	2900	3	336
65-315(I)A	60.5	16.8	106.4	57	30	2900	3	336
65-315(I)B	31	8.6	102.5	53	30	2900	3	273
65-315(I)B	44.5	12.4	100	53	30	2900	3	273
65-315(I)B	58	16.1	98	53	30	2900	3	273
80-100	35	9.72	13.8	67	3	2900	3	65
80-100	50	13.9	12.5	73	3	2900	3	65
80-100	65	18.1	10	70	3	2900	3	65
80-100A	31.3	8.7	11	66	2.2	2900	3	55
80-100A	44.7	12.5	10	72	2.2	2900	3	55
80-100A	58	16.1	8	69	2.2	2900	3	55
80-125	35	9.72	22	67	5.5	2900	3	100
80-125	50	13.9	20	72.5	5.5	2900	3	100
80-125	65	18.1	17	70	5.5	2900	3	100
80-125A	31.3	8.7	17.5	66	4	2900	3	80
80-125A	45	12.5	16	71	4	2900	3	80
80-125A	58	16.1	13.6	69	4	2900	3	80
80-160	35	9.72	35	63	7.5	2900	3	107
80-160	50	13.9	32	71	7.5	2900	3	107
80-160	65	18.1	28	70	7.5	2900	3	107
80-160A	32.7	9.1	30.6	62	7.5	2900	3.0	106
80-160A	46.7	13	28	70	7.5	2900	3.0	106
80-160A	61	16.9	24	69	7.5	2900	3.0	106
80-160B	30.3	8.4	26	61	5.5	2900	3	99
80-160B	43.3	12	24	69	5.5	2900	3	99
80-160B	56.33	15.6	21	68	5.5	2900	3	99
80-200	35	9.72	53.5	55	15	2900	3	177
80-200	50	13.9	50	69	15	2900	3	177
80-200	65	18.1	46	67	15	2900	3	177
80-200A	32.8	9.1	47	54	11	2900	3	166
80-200A	47	13.1	44	67	11	2900	3	166
80-200A	61	16.9	40	66	11	2900	3	166
80-200B	30.5	8.5	40.6	53	7.5	2900	3	116
80-200B	43.5	12.1	38	65	7.5	2900	3	116
80-200B	56.6	15.7	33.4	64	7.5	2900	3	116
80-250	35	9.72	83	52	22	2900	3	245
80-250	50	13.9	80	62	22	2900	3	245
80-250	65	18.1	72	59	22	2900	3	245
80-250A	32.5	9	73	51	18.5	2900	3	215
80-250A	46.7	13	70	60	18.5	2900	3	215
80-250A	61	16.9	63	58	18.5	2900	3	215
80-250B	30	8.3	62	50	15	2900	3	187
80-250B	43.3	12	60	58	15	2900	3	187
80-250B	56	15.6	54	57	15	2900	3	187
80-315	35	9.72	128	44	37	2900	3	360
80-315	50	13.9	125	54	37	2900	3	360
80-315	65	18.1	122	57	37	2900	3	360
80-315A	32.5	9	112	43	30	2900	3	342
80-315A	46.5	12.9	110	54	30	2900	3	342
80-315A	60.5	16.8	107	57	30	2900	3	342
80-315B	31	8.6	102	42	30	2900	3	342
80-315B	44.5	12.4	100	53	30	2900	3	342
80-315B	58	16.1	98	56	30	2900	3	342
80-315C	29	8.1	87	41	22	2900	3	277
80-315C	41	11.4	85	51	22	2900	3	277
80-315C	53.6	14.9	83	54	22	2900	3	277
80-350	35	9.72	156	53	55	2900	3	557
80-350	50	13.9	150	54	55	2900	3	557
80-350	60	16.7	142	52	55	2900	3	557
80-350A	30.8	8.56	148	45	45	2900	3	441
80-350A	44	12.2	142	51	45	2900	3	441
80-350A	52.8	14.7	135	50	45	2900	3	441
80-350B	28	7.78	142	39	37	2900	3	378
80-350B	40	11.1	135	48	37	2900	3	378
80-350B	46	12.8	128	46	37	2900	3	378
80-100(I)	70	19.4	14.0	66	5.5	2900	4.5	110
80-100(I)	100	27.8	12.5	76	5.5	2900	4.5	110
80-100(I)	130	36.1	11	75	5.5	2900	4.5	110
80-100(I)A	62.6	17.4	12	64	4	2900	4.5	88
80-100(I)A	89	24.7	10	74	4	2900	4.5	88
80-100(I)A	116	32.2	8.8	74	4	2900	4.5	88
80-125(I)	70	19.4	23.5	70	11	2900	4.5	164
80-125(I)	100	27.8	20	76	11	2900	4.5	164
80-125(I)	130	36.1	14	72	11	2900	4.5	164
80-125(I)A	62.6	17.4	19	68	7.5	2900	4.5	114
80-125(I)A	89	24.7	16	74	7.5	2900	4.5	114
80-125(I)A	116	32.2	11	65	7.5	2900	4.5	114
80-160(I)	70	19.4	36.5	70	15	2900	4.5	187
80-160(I)	100	27.8	32	76	15	2900	4.5	187
80-160(I)	130	36.1	24	65	15	2900	4.5	187
80-160(I)A	65.4	18.2	32	68	11	2900	4.5	175
80-160(I)A	93.5	26	28	74	11	2900	4.5	175
80-160(I)A	121	33.8	21	67	11	2900	4.5	175
80-160(I)B	60.6	16.8	27	66	11	2900	4.5	175
80-160(I)B	86.6	24.1	24	72	11	2900	4.5	175
80-160(I)B	112	31.3	18	65	11	2900	4.5	175
80-200(I)	70	19.4	54	65	22	2900	4	253
80-200(I)	100	27.8	50	74	22	2900	4	253
80-200(I)	130	36.1	42	73	22	2900	4	253
80-200(I)A	65.4	18.2	47.5	64	18.5	2900	4	221
80-200(I)A	93.5	26	44	73	18.5	2900	4	221
80-200(I)A	121	33.8	37	72	18.5	2900	4	221
80-200(I)B	61	16.9	41	62	15	2900	4	200
80-200(I)B	87	24.2	38	71	15	2900	4	200
80-200(I)B	113	31.4	32	70	15	2900	4	200
80-250 (I)	70	19.4	87	62	37	2900	4	333
80-250 (I)	100	27.8	80	71	37	2900	4	333
80-250 (I)	130	36.1	68	68	37	2900	4	333
80-250 (I) A	65.4	18.2	76	61	30	2900	4	315
80-250 (I) A	93.5	26.0	70	68	30	2900	4	315
80-250 (I) A	121	33.8	59.5	67	30	2900	4	315
80-250 (I) B	61	16.9	65	60	30	2900	4	271
80-250 (I) B	87	24.2	60	66	30	2900	4	271
80-250 (I) B	113	31.4	51	66	30	2900	4	271
80-315 (I)	70	19.4	132	55	75	2900	4	680
80-315 (I)	100	27.8	125	67	75	2900	4	680
80-315 (I)	130	36.1	114	66	75	2900	4	680
80-315 (I) A	66.5	18.5	119	59	55	2900	4	537
80-315 (I) A	95	26.4	113	65	55	2900	4	537
80-315 (I) A	123	34.3	103	64	55	2900	4	537
80-315 (I) B	63	17.5	106	58	45	2900	4	425
80-315 (I) B	90	25	101	65	45	2900	4	425
80-315 (I) B	117	32.5	92	63	45	2900	4	425
80-315 (I) C	58	16.1	90	56	37	2900	4	370
80-315 (I) C	82	22.8	85	63	37	2900	4	370
80-315 (I) C	107	29.7	76	61	37	2900	4	370
100-100	70	19.4	13.6	66	5.5	2900	4.5	115
100-100	100	37.8	12.5	76	5.5	2900	4.5	115
100-100	130	36.1	11	75	5.5	2900	4.5	115
100-100A	62.6	17.4	11	64	4	2900	4.5	93
100-100A	89	24.7	10	74	4	2900	4.5	93
100-100A	116	32.2	8.8	74	4	2900	4.5	93
100-125	70	19.4	23.5	70	11	2900	4.5	173
100-125	100	27.8	20	76	11	2900	4.5	173
100-125	130	36.1	14	65	11	2900	4.5	173
100-125A	62.5	17.4	19	68	7.5	2900	4.5	120
100-125A	89	24.7	16	74	7.5	2900	4.5	120
100-125A	116	32.2	11	63	7.5	2900	4.5	120
100-160	70	19.4	36.5	70	15	2900	4.5	194
100-160	100	27.8	32	76	15	2900	4.5	194
100-160	130	36.1	24	65	15	2900	4.5	194
100-160A	65.4	18.2	32	68	11	2900	4.5	182
100-160A	93.5	26	28	74	11	2900	4.5	182
100-160A	121	33.8	21	67	11	2900	4.5	182
100-160B	60.6	16.8	27	67	11	2900	4.5	182
100-160B	86.6	24.1	24	72	11	2900	4.5	182
100-160B	112	31.3	18	65	11	2900	4.5	182
100-200	70	19.4	54	65	22	2900	4	248
100-200	100	27.8	50	75	22	2900	4	248
100-200	130	36.1	42	73	22	2900	4	248
100-200A	65.4	18.2	47.5	64	18.5	2900	4	216
100-200A	93.5	26	44	73	18.5	2900	4	216
100-200A	121	33.8	37	72	18.5	2900	4	216
100-200B	61	16.9	41	63	15	2900	4	195
100-200B	87	24.2	38	71	15	2900	4	195
100-200B	113	31.4	32	70	15	2900	4	195
100-250	70	19.4	87	62	37	2900	4	348
100-250	100	27.8	80	71	37	2900	4	348
100-250	130	36.1	68	68	37	2900	4	348
100-250A	65.4	18.2	76	61	30	2900	4	332
100-250A	93.5	26	70	68	30	2900	4	332
100-250A	121	33.8	59.5	67	30	2900	4	332
100-250B	61	16.9	65	59	30	2900	4	332
100-250B	87	24.2	60	66	30	2900	4	332
100-250B	113	31.4	51	65	30	2900	4	332
100-315	70	19.4	132	55	75	2900	4	695
100-315	100	27.8	125	67	75	2900	4	695
100-315	130	36.1	114	66	75	2900	4	695
100-315A	66.5	18.5	119	55	55	2900	4	552
100-315A	95	26.4	113	65	55	2900	4	552
100-315A	123	34.3	103	64	55	2900	4	552
100-315B	63	17.5	106	51	45	2900	4	442
100-315B	90	25	101	65	45	2900	4	442
100-315B	117	32.5	92	63	45	2900	4	442
100-350	60	16.7	153.6	72	90	2900	4	777
100-350	100	27.8	150	57	90	2900	4	777
100-350	120	33.3	142	74	90	2900	4	777
100-350A	61	16.9	145.6	75	75	2900	4	683
100-350A	87	24.2	142	75	75	2900	4	683
100-350A	113	31.4	134	75	75	2900	4	683
100-350B	58	16.1	138.6	75	55	2900	4	536
100-350B	82	22.8	135	75	55	2900	4	536
100-350B	107	29.7	127	75	55	2900	4	536
100-100(I)	96	26.7	14	64	11	2900	4	110
100-100(I)	160	44.4	12.5	73	11	2900	4	110
100-100(I)	192	53.3	10	70	11	2900	4	110
100-125(I)	96	26.7	24	62	15	2900	4	168
100-125(I)	160	44.4	20	74	15	2900	4	168
100-125(I)	192	53.3	14	69	15	2900	4	168
100-125(I)A	84	23.3	20	64	11	2900	4	160
100-125(I)A	140	39	17	72	11	2900	4	160
100-125(I)A	168	46.7	12	68	11	2900	4	160
100-160(I)	96	26.7	36	69	22	2900	4	210
100-160(I)	160	44.4	32	79	22	2900	4	210
100-160(I)	192	53.3	27	75	22	2900	4	210
100-160(I)A	84	23.3	32	66	18.5	2900	4	205
100-160(I)A	140	39	28	76	18.5	2900	4	205
100-160(I)A	168	46.7	23.5	72	18.5	2900	4	205
100-200(I)	96	26.7	54	65	37	2900	4	348
100-200(I)	160	44.4	50	77	37	2900	4	348
100-200(I)	192	53.3	46	75	37	2900	4	348
100-200(I)A	84	23.3	47.5	64	30	2900	4	332
100-200(I)A	140	39	44	76	30	2900	4	332
100-200(I)A	168	46.7	40.5	75	30	2900	4	332
100-200(I)B	60	23.6	40	63	30	2900	4	331
100-200(I)B	138	38.3	37	75	30	2900	4	331
100-200(I)B	170	47.2	34	75	30	2900	4	331
100-250(I)	96	26.7	83	65	55	2900	4	560
100-250(I)	160	44.4	80	77	55	2900	4	560
100-250(I)	192	53.3	72	74	55	2900	4	560
100-250(I)A	84	23.3	75	60	45	2900	4	540
100-250(I)A	140	39	72	72	45	2900	4	540
100-250(I)A	168	46.7	65	69	45	2900	4	540
100-250(I)B	60	16.7	68	70	37	2900	4	520
100-250(I)B	100	27.8	65	70	37	2900	4	520
100-250(I)B	120	33.3	58	70	37	2900	4	520
125-100	96	26.7	13	82	11	2900	4	185
125-100	160	44.4	12.5	82	11	2900	4	185
125-100	192	53.3	12	82	11	2900	4	185
125-100A	86	23.9	10.4	77	7.5	2900	4	130
125-100A	143	39.7	10	77	7.5	2900	4	130
125-100A	172	47.8	9.6	77	7.5	2900	4	130
125-125	96	26.7	22.6	80	15	2900	4	227
125-125	160	44.4	20	80	15	2900	4	227
125-125	192	53.3	17	80	15	2900	4	227
125-125A	86	23.9	18	77	11	2900	4	215
125-125A	143	39.7	16	77	11	2900	4	215
125-125A	172	47.8	13.6	77	11	2900	4	215
125-160	96	26.7	36	78	22	2900	4	272
125-160	160	44.4	32	78	22	2900	4	272
125-160	192	53.3	28	78	22	2900	4	272
125-160A	90	25	31.5	76	18.5	2900	4	215
125-160A	150	41.7	28	76	18.5	2900	4	215
125-160A	180	50	24.5	76	18.5	2900	4	215
125-160B	83	21.7	27	73	15	2900	4	182
125-160B	138	38.3	24	73	15	2900	4	182
125-160B	166	46.1	21	73	15	2900	4	182
125-200	96	26.7	55	77	37	2900	4	386
125-200	160	44.4	50	77	37	2900	4	386
125-200	192	53.3	46	77	37	2900	4	386
125-200A	90	25	48.4	76	30	2900	4	365
125-200A	150	41.7	44	76	30	2900	4	365
125-200A	180	50	40.5	76	30	2900	4	365
125-200B	83	21.7	41.3	75	22	2900	4	302
125-200B	138	38.3	37.5	75	22	2900	4	302
125-200B	166	46.1	34.5	75	22	2900	4	302
125-250	96	26.7	87	75	55	2900	4	562
125-250	160	44.4	80	75	55	2900	4	562
125-250	192	53.3	73	75	55	2900	4	562
125-250A	90	25	76	74	45	2900	4	457
125-250A	150	41.7	70	74	45	2900	4	457
125-250A	180	50	64	74	45	2900	4	457
125-250B	83	21.7	65	73	37	2900	4	404
125-250B	138	33.3	60	73	37	2900	4	404
125-250B	166	46.1	55	73	37	2900	4	404
125-315	96	26.7	133	70	90	2900	4	756
125-315	160	44.7	125	70	90	2900	4	756
125-315	192	53.3	119	70	90	2900	4	756
125-315A	90	25	117	70	75	2900	4	651
125-315A	150	41.7	110	70	75	2900	4	651
125-315A	180	50	104	70	75	2900	4	651
125-315B	86	23.9	106	69	75	2900	4	646
125-315B	143	39.7	100	69	75	2900	4	646
125-315B	172	47.8	95.2	69	75	2900	4	646
125-315C	80.5	22.4	96	67	55	2900	5	585
125-315C	134	37.2	88	67	55	2900	5	585
125-315C	161	44.7	86	67	55	2900	5	585
150-125	96	26.7	22.6	66	15	2900	4	236
150-125	160	44.7	24	76	15	2900	4	236
150-125	192	53.3	17	76	15	2900	4	236
150-125A	90	25	18	71	11	2900	4	226
150-125A	150	41.7	16	71	11	2900	4	226
150-125A	180	50	13.6	71	11	2900	4	226
150-160	96	26.7	35	72	22	2900	4	294
150-160	160	44.4	32	78	22	2900	4	294
150-160	192	53.3	28	76	22	2900	4	294
150-160A	90	25	31.5	71	18.5	2900	4	252
150-160A	150	41.7	28	76	18.5	2900	4	252
150-160A	180	50	24.5	73	18.5	2900	4	252
150-160B	84	23.3	27	67	15	2900	4	231
150-160B	140	38.9	24	73	15	2900	4	231
150-160B	168	46.7	21	72	15	2900	4	231
150-200	96	26.7	55	77	37	2900	4	410
150-200	160	44.4	50	77	37	2900	4	410
150-200	192	53.3	46	77	37	2900	4	410
150-200A	90	25	48.4	76	30	2900	4	385
150-200A	150	41.7	44	76	30	2900	4	385
150-200A	180	50	40.5	76	30	2900	4	385
150-200B	83	21.7	41.3	75	22	2900	4	315
150-200B	138	33.3	37.5	75	22	2900	4	315
150-200B	166	46.1	34.5	75	22	2900	4	315
150-250(I)	120	33.3	87	65	75	2900	4	761
150-250(I)	200	55.6	80	76	75	2900	4	761
150-250(I)	240	66.7	72	74	75	2900	4	761
150-250(I)A	112	31.1	76	64	55	2900	4	614
150-250(I)A	187	51.9	70	75	55	2900	4	614
150-250(I)A	224	62.2	63	73	55	2900	4	614
150-250(I)B	104	26.9	65	63	45	2900	4	509
150-250(I)B	173	48.1	60	74	45	2900	4	509
150-250(I)B	208	57.8	54	72	45	2900	4	509
150-315(I)	120	33.3	133	57	110	2900	4.5	1029
150-315(I)	200	55.6	125	75	110	2900	4.5	1029
150-315(I)	240	66.7	120	73	110	2900	4.5	1029
150-315(I)A	112	31.1	116	57	90	2900	4.5	767
150-315(I)A	187	51.9	110	74	90	2900	4.5	767
150-315(I)A	224	62.2	105	72	90	2900	4.5	767
150-315(I)B	104	28.9	100	55	75	2900	4.5	746
150-315(I)B	173	48.1	95	72	75	2900	4.5	746
150-315(I)B	208	57.8	91	70	75	2900	4.5	746
150-350	96	26.7	153.6	69	110	2900	4.5	1040
150-350	160	44.4	150	70	110	2900	4.5	1040
150-350	192	53.3	138	67	110	2900	4.5	1040
150-350A	105	27.2	152	68	90	2900	4.5	777
150-350A	150	41.7	142	69	90	2900	4.5	777
150-350A	180	50	130	65	90	2900	4.5	777
150-350B	98	27.2	110	63	75	2900	4.5	756
150-350B	140	38.9	101	67	75	2900	4.5	756
150-350B	168	46.7	90	60	75	2900	4.5	756
150-200	140	38.9	13.8	68	15	1450	3.0	278
150-200	200	55.6	12.5	78	15	1450	3.0	278
150-200	260	72.2	10.6	78	15	1450	3.0	278
150-200A	125	34.7	11.5	66	11	1450	3.0	263
150-200A	176	49.7	10	76	11	1450	3.0	263
150-200A	232	64.6	8.5	76	11	1450	3.0	263
150-250	140	38.9	21.8	73	18.5	1450	3.0	355
150-250	184	55.6	20	80	18.5	1450	3.0	355
150-250	260	72.2	17	77	18.5	1450	3.0	355
150-250A	129	35.8	18.5	72	15	1450	3.0	315
150-250A	184	51.1	17	78	15	1450	3.0	315
150-250A	240	66.7	14.4	76	15	1450	3.0	315
150-250B	117	32.5	15.2	70	11	1450	3.0	294
150-250B	167	46.4	14	76	11	1450	3.0	294
150-250B	217	60.4	12	74	11	1450	3.0	294
150-315	140	38.9	33.8	70	30	1450	3.5	462
150-315	200	55.6	32	78	30	1450	3.5	462
150-315	260	72.7	28	73	30	1450	3.5	462
150-315A	131	36.4	29.5	69	22	1450	3.5	378
150-315A	187	51.9	28	77	22	1450	3.5	378
150-315A	243	67.5	24.5	77	22	1450	3.5	378
150-315B	121	33.6	25	69	18.5	1450	3.5	368
150-315B	173	48.1	24	76	18.5	1450	3.5	368
150-315B	225	62.3	21	75	18.5	1450	3.5	368
150-400	140	38.9	53	68	45	1450	3.5	620
150-400	200	55.6	50	75	45	1450	3.5	620
150-400	260	72.2	46	71	45	1450	3.5	620
150-400A	131	36.4	46.6	67	37	1450	3.5	578
150-400A	187	51.9	44	74	37	1450	3.5	578
150-400A	243	67.5	38.3	70	37	1450	3.5	578
150-400B	122	33.9	40	64	30	1450	3.5	546
150-400B	174	48.3	38	73	30	1450	3.5	546
150-400B	226	62.9	33	70	30	1450	3.5	546
150-400C	112	31.1	34	64	22	1450	3.5	515
150-400C	160	44.4	32	71	22	1450	3.5	515
150-400C	208	57.8	28	69	22	1450	3.5	515
200-200	140	38.9	13.8	67	15	1450	3	404
200-200	200	55.6	12.5	78	15	1450	3	404
200-200	260	72.2	10.6	78	15	1450	3	404
200-200A	125	34.7	11	66	11	1450	3	383
200-200A	179	49.7	10	76	11	1450	3	383
200-200A	232	64.6	8.5	76	11	1450	3	383
200-250	140	38.9	21.8	73	18.5	1450	3	450
200-250	200	55.6	20	80	18.5	1450	3	450
200-250	260	72.2	17	77	18.5	1450	3	450
200-250A	129	35.8	18.5	72	15	1450	3	438
200-250A	184	51.2	17	78	15	1450	3	438
200-250A	240	66.7	14.4	76	15	1450	3	438
200-250B	117	32.5	15.2	70	11	1450	3	404
200-250B	167	46.4	14	76	11	1450	3	404
200-250B	217.5	60.4	12	75	11	1450	3	404
200-315	140	38.9	33.8	70	30	1450	3.5	578
200-315	200	55.6	32	78	30	1450	3.5	578
200-315	260	72.2	28	78	30	1450	3.5	578
200-315A	131	36.4	29.5	69	22	1450	3.5	483
200-315A	187	51.9	28	77	22	1450	3.5	483
200-315A	243	67.5	24.5	77	22	1450	3.5	483
200-315B	121	33.6	25.5	69	18.5	1450	3.5	462
200-315B	173	48.1	24	76	18.5	1450	3.5	462
200-315B	225	62.5	20.5	75	18.5	1450	3.5	462
200-400	140	38.9	53	68	45	1450	3.5	620
200-400	200	55.6	50	75	45	1450	3.5	620
200-400	260	72.2	44	71	45	1450	3.5	620
200-400A	131	36.4	46.6	67	37	1450	3.5	578
200-400A	187	51.9	44	74	37	1450	3.5	578
200-400A	243	67.5	38.3	70	37	1450	3.5	578
200-400B	122	33.9	40	64	30	1450	3.5	546
200-400B	174	48.6	38	73	30	1450	3.5	546
200-400B	226	62.9	33	70	30	1450	3.5	546
200-400C	112	31.3	34	64	22	1450	3.5	515
200-400C	160	44.4	32	71	22	1450	3.5	515
200-400C	208	57.8	28	69	22	1450	3.5	515
200-200(I)	280	77.8	13.4	70	22	1450	4	452
200-200(I)	400	111	12.5	80	22	1450	4	452
200-200(I)	520	144	10.5	79	22	1450	4	452
200-200(I)A	250	69.4	11.2	68	18.5	1450	4	452
200-200(I)A	358	99.4	10	78	18.5	1450	4	452
200-200(I)A	465	129	8.5	77	18.5	1450	4	452
200-250(I)	280	77.8	22.2	75	30	1450	4	525
200-250(I)	400	111	20	80	30	1450	4	525
200-250(I)	520	144	14	72	30	1450	4	525
200-250(I)A	250	69.4	18	73	22	1450	4	431
200-250(I)A	358	99.4	16	78	22	1450	4	431
200-250(I)A	465	129	11.2	70	22	1450	4	431
200-250(I)B	226	62.8	14.4	70	18.5	1450	4	420
200-250(I)B	322	89.4	13	75	18.5	1450	4	420
200-250(I)B	419	116	9.3	67	18.5	1450	4	420
200-315(I)	280	77.8	36	73	55	1450	4	756
200-315(I)	400	111	32	80	55	1450	4	756
200-315(I)	520	144	26	75	55	1450	4	756
200-315(I)A	262	72.8	31.5	72	45	1450	4	651
200-315(I)A	374	103	28	79	45	1450	4	651
200-315(I)A	486	135	23	74	45	1450	4	651
200-315(I)B	242	67.2	27	71	37	1450	4	599
200-315(I)B	346	96.1	24	78	37	1450	4	599
200-315(I)B	450	125	19.5	73	37	1450	4	599
200-400(I)	280	77.8	54.5	75	75	1450	4	1008
200-400(I)	400	111.4	50	81	75	1450	4	1008
200-400(I)	520	144	39	77	75	1450	4	1008
200-400(I)A	262	72.8	48	74	75	1450	4	893
200-400(I)A	374	103	44	80	75	1450	4	893
200-400(I)A	486	135	34	76	75	1450	4	893
200-400(I)B	242	67.2	41.4	72	55	1450	5	746
200-400(I)B	346	96.1	38	78	55	1450	5	746
200-400(I)B	450	125	29.6	74	55	1450	5	746
200-400(I)C	224	62.2	34.9	70	45	1450	5	635
200-400(I)C	320	88.9	32	76	45	1450	5	635
200-400(I)C	416	115	25	72	45	1450	5	635
200-500	284	77.8	85	76	132	1450	4	1254
200-500	400	111.1	80	78	132	1450	4	1254
200-500	520	144.4	70	76	132	1450	4	1254
200-500(I)A	262	72.8	74.4	75	110	1450	4	1184
200-500(I)A	374	103.9	70	77	110	1450	4	1184
200-500(I)A	486	135	61.2	75	110	1450	4	1184
200-500(I)B	242	62.2	63.8	74	90	1450	4	1088
200-500(I)B	346	96.1	60	76	90	1450	4	1088
200-500(I)B	450	125	52.5	74	90	1450	4	1088
200-500(I)C	224	62.2	53.2	73	75	1450	4	980
200-500(I)C	320	88.9	50	75	75	1450	4	980
200-500(I)C	416	115.6	43.8	73	75	1450	4	980
250-250	350	97.2	22	78	45	1450	5	620
250-250	550	152.8	20	82	45	1450	5	620
250-250	650	180.5	16	81	45	1450	5	620
250-250A	300	83.3	18.3	76	37	1450	5	550
250-250A	500	139	17	80	37	1450	5	550
250-250A	600	166.7	14	80	37	1450	5	550
250-315	350	97.2	34	76	75	1450	5	915
250-315	550	152.8	32	80	75	1450	5	915
250-315	650	180.5	28	79	75	1450	5	915
250-315A	300	83.3	29.5	74	55	1450	5	840
250-315A	500	139	28	78	55	1450	5	840
250-315A	600	166.7	24	77	55	1450	5	840
250-315B	260	72.2	25	70	45	1450	5	695
250-315B	450	125	24	74	45	1450	5	695
250-315B	520	144.4	20	72	45	1450	5	695
250-400	400	111.1	54.5	75	110	1480	5	1557
250-400	550	152.8	50	78	110	1480	5	1557
250-400	670	186.7	39	80	110	1480	5	1557
250-400A	365	101.4	47	74	90	1450	5.0	1055
250-400A	500	138.9	44	77	90	1450	5.0	1055
250-400A	600	166.7	35	79	90	1450	5.0	1055
250-400B	325	90.3	41.2	73	75	1450	5.0	910
250-400B	450	125	38	76	75	1450	5.0	910
250-400B	530	147.2	34.2	78	75	1450	5.0	910
250-480	400	111.1	76	75	160	1450	5.0	1545
250-480	550	152.8	70	76	160	1450	5.0	1545
250-480	670	186.7	63	78	160	1450	5.0	1545
250-480A	365	101.4	65	74	132	1450	5.0	1355
250-480A	500	138.9	60	75	132	1450	5.0	1355
250-480A	600	166.7	54	77	132	1450	5.0	1355
250-480B	325	90.3	55	73	90	1450	5.0	1055
250-480B	450	125	50	74	90	1450	5.0	1055
250-480B	530	147.2	42	74	90	1450	5.0	1055
300-235	540	150	20.5	77	55	1450	5	1135
300-235	720	200	18	81	55	1450	5	1135
300-235	900	250	15	74	55	1450	5	1135
300-235A	450	125	17.2	74	45	1450	5	1040
300-235A	600	166	15	79	45	1450	5	1040
300-235A	720	200	12.5	77	45	1450	5	1040
300-235B	420	116.7	14.3	73	37	1450	5	900
300-235B	540	150	12.8	78	37	1450	5	900
300-235B	650	181	10.5	70	37	1450	5	900
300-250	540	150	22.5	80	55	1450	5	1370
300-250	720	200	20	83	55	1450	5	1370
300-250	900	250	17	84	55	1450	5	1370
300-250A	450	136	19.5	81	45	1450	5	1190
300-250A	600	166	17	81	45	1450	5	1190
300-250A	720	200	14	81	45	1450	5	1190
300-300	540	150	32	82	75	1480	5	1930
300-300	720	200	28	82	75	1480	5	1930
300-300	900	250	23	82	75	1480	5	1930
300-300A	450	125	27.5	80	75	1480	5	1725
300-300A	600	166	24	80	75	1480	5	1725
300-300A	720	200	20	80	75	1480	5	1725
300-300B	420	116.7	24	78	55	1480	5	1550
300-300B	540	150	21	78	55	1480	5	1550
300-300B	650	181	17	78	55	1480	5	1550
300-380	480	133.3	48	76	132	980	5	1930
300-380	720	200	44	84	132	980	5	1930
300-380	900	250	34	82	132	980	5	1930
300-380A	444	123.3	41.4	81	110	980	5	1725
300-380A	666	185	38	81	110	980	5	1725
300-380A	833	231.4	30	81	110	980	5	1725
300-380B	400	113.6	35	80	90	980	5	1550
300-380B	614	170.6	32	80	90	980	5	1550
300-380B	764	213.1	25	80	90	900	5	1550
300-315	540	150	35	76	90	1450	5	1418
300-315	720	200	32	84	90	1450	5	1418
300-315	900	250	26	80	90	1450	5	1418
300-315A	460	127.8	31.5	72	75	1480	5	1302
300-315A	650	180	28	80	75	1480	5	1302
300-315A	800	222	23.5	77	75	1480	5	1302
300-315B	420	116.7	27	71	55	1480	5	1155
300-315B	580	161	24	78	55	1480	5	1155
300-315B	700	194	20	76	55	1480	5	1155
300-400	500	138.9	54.5	80	132	1450	5.5	1760
300-400	720	200	50	80	132	1450	5.5	1760
300-400	900	250	42	80	132	1450	5.5	1760
300-400A	420	127.8	47	78	110	1450	5.5	1550
300-400A	600	180.6	44	78	110	1450	5.5	1550
300-400A	780	233.3	37	78	110	1450	5.5	1550
300-460	480	133.3	71	75	185	1450	5.5	2250
300-460	720	200	65	81	185	1450	5.5	2250
300-460	900	250	58	82	185	1450	5.5	2250
300-460A	444	123.3	60	74	160	1450	5.5	1780
300-460A	666	185	55	80	160	1450	5.5	1780
300-460A	833	231.4	49	81	160	1450	5.5	1780
300-460B	409	113.6	49	73	110	1450	5.5	1680
300-460B	614	170.6	45	79	110	1450	5.5	1680
300-460B	767	213.1	35	80	110	1450	5.5	1680
300-500	540	150	85	78	250	1450	5.5	1680
300-500	720	200	80	80	250	1450	5.5	1680
300-500	900	250	70	78	250	1450	5.5	1680
300-500A	506	140.6	74.4	77	200	1450	5.5	1665
300-500A	675	187.5	70	79	200	1450	5.5	1665
300-500A	720	200	61.2	77	200	1450	5.5	1665
300-500B	468	130	63.8	76	160	1450	5.5	1472
300-500B	625	173.6	60	78	160	1450	5.5	1472
300-500B	667	185.3	52.5	76	160	1450	5.5	1472
300-500C	425	118	53.2	75	110	1450	5.5	1345
300-500C	570	158.3	50	77	110	1450	5.5	1345
300-500C	605	168	43.8	75	110	1450	5.5	1345
300-235(I)	718	199.4	44.6	82	160	1450	5.5	1680
300-235(I)	1080	300	40	82	160	1450	5.5	1680
300-235(I)	1345	373.6	34.6	82	160	1450	5.5	1680
300-235(I)A	642	178.3	35.7	80	132	1450	5.5	1450
300-235(I)A	965	268.1	32	80	132	1450	5.5	1450
300-235(I)A	1203	334.2	27.7	80	132	1450	5.5	1450
350-250	480	133.3	23	79	75	1450	5.0	1292
350-250	800	222	20	82	75	1450	5.0	1292
350-250	960	267	17.5	81	75	1450	5.0	1292
350-250A	430	119.4	18.5	81	55	1450	5.0	1230
350-250A	715	198.6	16	81	55	1450	5.0	1230
350-250A	860	238.9	13	81	55	1450	5.0	1230
350-315	480	133.3	35	75	90	1450	5.0	1733
350-315	800	222	32	81	90	1450	5.0	1733
350-315	960	267	27	80	90	1450	5.0	1733
350-315A	450	125	30.5	80	75	1450	5.0	1350
350-315A	748	207.8	28	80	75	1450	5.0	1350
350-315A	900	250	23.5	80	75	1450	5.0	1350
350-315B	416	115.6	26	78	75	1450	5.0	1350
350-315B	692	192.2	24	78	75	1450	5.0	1350
350-315B	832	231.1	20	78	75	1450	5.0	1350
350-400	480	133.3	55	76	160	1450	5.0	2048
350-400	800	222	50	82	160	1450	5.0	2048
350-400	960	267	45.5	80	160	1450	5.0	2048
350-400A	450	125	48	80	132	1450	5.0	1950
350-400A	748	207.8	44	80	132	1450	5.0	1950
350-400A	900	250	40	80	132	1450	5.0	1950
350-400B	418	116.1	42	78	110	1450	5.0	1920
350-400B	697	193.6	38	78	110	1450	5.0	1920
350-400B	836	232.2	34.5	78	110	1450	5.0	1920
350-460	1000	277.8	55	74	250	1450	6.0	2350
350-460	1200	333.3	50	74	250	1450	6.0	2350
350-460	1450	402.8	43	74	250	1450	6.0	2350
350-460A	900	250	47	72	200	1450	6.0	2100
350-460A	1080	300	44	72	200	1450	6.0	2100
350-460A	1300	360	39	72	200	1450	6.0	2100
350-480	610	169.4	71	75	220	1450	5.5	2100
350-480	850	236.1	65	81	220	1450	5.5	2100
350-480	1020	283.3	58	79	220	1450	5.5	2100
350-480A	574	159.4	65	75	200	1450	5.5	2350
350-480A	800	222.2	60	80	200	1450	5.5	2350
350-480A	960	266.7	53	79	200	1450	5.5	2350
350-480B	516	143.3	60	72	160	1450	5.5	2250
350-480B	720	200	55	78	160	1450	5.5	2250
350-480B	864	240	45	75	160	1450	5.5	2250
400-300	820	228	23	72	90	1450	5.5	1649
400-300	1080	300	20	78	90	1450	5.5	1649
400-300	1300	361	16	75	90	1450	5.5	1649
400-315	820	228	36.5	71	132	1450	5.5	1970
400-315	1080	300	32	76	132	1450	5.5	1970
400-315	1300	361	27	74	132	1450	5.5	1970
500-300	1000	277.8	23	76	110	1450	5.5	1890
500-300	1200	333	20	80	110	1450	5.5	1890
500-300	1450	403	16	75	110	1450	5.5	1890
500-315	1000	278	34.5	76	160	1450	5.5	2174
500-315	1200	333	32	78	160	1450	5.5	2174
500-315	1450	403	27	77	160	1450	5.5	2174

Q1: What is the main application difference between the ISW and IHW series models?

The ISW series is designed for clean water and fluids with physical properties similar to water, widely used in municipal water supply, HVAC cooling/heating circulation, and fire protection systems. The IHW series is an upgraded chemical-grade end suction pump made of corrosion-resistant materials (304/316 Stainless Steel or Duplex Steel) for handling aggressive industrial chemicals, solvents, and process fluids.

Q2: What is the operational advantage of the close-coupled horizontal end suction structure?

The horizontal end suction design features an axial inlet and vertical top outlet for optimal hydraulic flow efficiency. By eliminating traditional flexible couplings, the close-coupled alignment ensures zero shaft offset, reduces mechanical vibration, extends mechanical seal life, and minimizes the overall installation footprint on the equipment pad.

Q3: How do I choose between Cast Iron, Stainless Steel, and Duplex Steel for my specific piping process?

Cast Iron: Ideal for standard HVAC cooling towers, boiler feed water, civil booster systems, and non-corrosive industrial water.

Stainless Steel (304/316): Suitable for food and beverage processes, deionized water, light acid/alkali chemicals, and pharmaceutical manufacturing.

Duplex Steel: Engineered for highly corrosive environments with high chloride content, such as seawater intake, desalination plants, and harsh chemical production lines.

Q4: Is the ISW/IHW pump self-priming, and how should it be installed when pumping from lower liquid levels?

No, it is a non-self-priming end suction centrifugal pump. For installations where the fluid source is located below the pump centerline (negative suction head), a foot valve must be installed on the suction line and the casing must be manually filled prior to startup. Alternatively, a flooded suction installation (positive head) is recommended.

Q5: What maintenance features are designed to reduce plant downtime?

The pump is built with a back-pull-out structural concept (when using spacer couplings or specific configurations) and an integrated shaft system. Servicing or replacing mechanical seals, impellers, and bearings can be completed without disconnecting the suction and discharge pipe flanges or the base foundation, drastically shortening maintenance cycles and reducing labor costs.

Recommend Products

CONTACT JIUJIANG

Send A Message

Telephone

+86 18167392360

Mailbox

sales@jpzxpumps.com

Address

No.16 Linwu Road, Oubei Street, Yongjia, Wenzhou, Zhejiang, China

Sitemap

CONTENTS

PRODUCT CATEGORY

CONTACT

About Us

Solution

New & Blog

Self-Priming Centrifugal Pumps

Industrial Water Pumps

Diesel Engine Pumps

View All Products

Tell: +86 18167392360

Address: No.16 Linwu Road, Oubei Street, Yongjia, Wenzhou, Zhejiang, China

Email: sales@jpzxpumps.com

LEGAL POLICY
